Stabilized Remote Head SRH-360
Powerful and extremely flexible
The SRH-360 is an upgraded version of ARRI's SRH-3.
The major improvement with the SRH-360 is to the pan axis functionality: A new slip ring permits unlimited rotation of the head. At the same time, the torque of the pan motor has been increased by 50%, allowing it to compensate for powerful centrifugal forces when shooting high-speed camera moves. This makes the SRH-360 even more flexible for dynamic environments such as action, stunts, vehicle work, sports, and live music performances.
SRH-360 Product Feature Tour
Technical data SRH-360
|
|
|
Stabilized Axis |
|
|
Max. Payload |
|
|
Height |
|
|
Width |
|
|
Depth Head |
|
|
Depth Base |
|
|
Ring Diameter |
|
|
Ring Height centre |
|
|
Weight |
|
|
Max. Tilt Range |
|
|
Max. Roll Range |
|
|
Max. Pan Range |
|
|
Max. Pan Rate |
|
|
Max. Tilt Rate |
|
|
Operating Voltage SRH |
|
|
Output Camera |
|
|
Current |
|
|
LBUS socket |
|
|
RS socket |
|
|
Video |
|
|
SAM plates compatible |
|
|
Environmental |
|
|
3 (Pan, Tilt, Roll) |
up to 30Kg/66lbs |
65,2cm/25.67in |
41,2cm/16.22in |
15 cm/5.9in |
24,6cm/9.68in |
26cm/10.23in |
20,9cm/8.23in |
11,6Kg/25.57lbs |
+60° / - 110° |
+/- 90° |
Slip Ring, Unlimited |
240° / Sec. |
240° / Sec. |
24V - 36V |
12V & 24V |
10 Amps |
Yes |
Yes |
up to 12 G single link support |
Yes |
-20° to +50° / -4° F to 122° F |
Smart and adaptive system
To provide outstanding stabilization, the motors inside the ARRI Stabilized Remote Heads can compensate for external centrifugal force by adding extra motor power.
The SRH-3 and SRH-360 can also be remote controlled with ARRI's joystick control board with optional wheels.
High payload, low weight, compact design
The ARRI SRH-3 and SRH-360 are extremely compact and lightweight. However, the low weight does not equate to lower support capabilities: each Stabilized Remote Head is capable of handling payloads in excess of the three times their own weight (up to 60lbs, 30kg), which represents the best weight-to-payload ratio available in the market
Future-proof workflows
The ARRI Stabilized Remote Heads are perfectly compatible with other ARRI products and workflows, but can also be used with a variety of competing brands. ARRI stands behind its products, continually offering years of service and updates to users.
Budget-friendly
When working with high-end capturing systems, there is no sense in compromising on a stabilized remote head due to the price tag. The ARRI Stabilized Remote Heads have taken expense into consideration. Despite their premium features, the SRH-3 and SRH-360 are budget friendly.
